• Spectrum-analyzer 2-900MHz and 950-2150MHz. • Presents full range and expanded spectrum. • Very high accuracy, CATV +/-1dB, SAT-TV +/- 1.5dB at 20°C. • Digital BER, MER and S/N(C/N)-ratio DVB-S/S2. • Digital BER, MER and S/N(C/N)-ratio DVB-T/T2. • Digital BER and S/N(C/N)-ratio DVB-C. • DVB-S FTA receiver with picture (MPEG-2). • DVB-T FTA receiver with picture (MPEG-2). • DVB-C FTA receiver with picture (MPEG-2). • Automatic Satellite identifcation. • Readout of NIT - gives SAT ID and TV/Radio-channel info. • QPSK and 8PSK constellation diagram for DVB-S/S2. • Aerial power output, 0, 12, 18 and 24V. • LNB voltage 13/18V, 22KHz tone switch, Sat-CR control. • DiSEqC according to level 1.0, 1.1 and 1.2. • Lots of memory positions for spectrum pictures. • RS232 for PC-connection (up/download). • Rechargeable Li-Ion battery. • Nice & small, only 4Kg complete with carrying case.
Input frequency: 2-900 Mhz and 920-2150MHz. Sat-TV min level in: About 35 dBuV (noise). Sat-TV max level in: About 90 dBuV. TV-part max input level, picture: 110 dByV. Spectrum: 120 dByV. Sat-TV attenuation: 15 dB attenuator on/off. TV-part: attenuation: 45 dB in 1 dB step. Display of signallevel (analog): dB on LCD/monitor. Pitch-tone. Sat-TV accuracy: ±1½ dB (at +20° C). TV-part accuracy: ±1 dB (at +20° C). TV-part resolution bandwidth: 1 MHz or 300 kHz. TV-part video bandwidth: 100, 10 ,1 kHz or 100Hz. DVB-S/S2 Digital display of signallevel: S/N (signal/noise-ratio) BER (bit error rate) Constellation (QPSK and 8PSK). DVB-T/T2 Digital display of signallevel: C/N (carrier/noise-ratio) BER (bit error rate) transmission parameters. Satellite-indentification: Yes, by reading out the NIT in the bitstream. Info about the TV- and Radio- channels. KU- C-band: Yes, selectable. Input impedance: 75 Ohm, F-con. Picture-screen: 5” 16:9 TFT-LCD monitor Menus: On LCD 64x128. Memory: - Lots of spectrum pictures can be stored with name. Stored spectrum can be mixed for easy identification of satellite. -“Maxhold”-function. Favouritechannels: Frequencies can be stored (with name). Free to Air channels on DVB-S, DVB-T and DVB-C (MPEG2) can be viewed. PC-connection: RS232-output and PC-software. Sat-TV power out: Yes, 13-18V. TV power out: On/off. 12-24 volt. Sat-TV control: 22 kHz, DiSEqC SatCr (UniCable). DiSEqC Yes, all 1.0 and 1.1. 1.2. DiSEqC actuator: Built in positioner for DiSEqC 1.2, SAT-CR Unicable control with tests. Battery: Rechargable 12v, 3.5 amp/hour. Weight: About 4 kg incl.battery. Accessories: Nylon carrying-case. Power-supply of 220v/13.5v, 1.7amp.
Technical specification:
